INTRODUCTION


This document details the URLs needed to get RTSP Video Streams from VISTA VK2 and OPTIO IP Cameras.


VISTA VK2 Camera Range

It is possible to Pull a JPEG snapshot image as well as an RTSP video stream from a camera;



(NOTE: ch = channel\stream number e.g. 1, 2 or 3 and the JPEG resolution will follow that of the RTSP setting for the stream)



  • RTSP Streams
    • rtsp://username:password@<IPAddress>:554/1/streamS



(NOTE: S = stream number e.g. 1, 2, 3 or 4 and the resolution and H264/265 compression will follow that of the setting in the cameras Stream configuration)

  • Examples;
    • rtsp://admin:admin@192.168.30.220:554/1/stream1 (H.264\H.265)
    • rtsp://admin:admin@192.168.30.220:554/1/stream2 (MJPEG)
    • rtsp://admin:admin@192.168.30.220:554/1/stream3 (H.264\H.265)
    • rtsp://admin:admin@192.168.30.220:554/1/stream4 (H.264\H.265) [Stream 4 only available on 2MPX & 4MPX]



(NOTE:  H.265 & Stream 4 support dependent on camera please check camera specification)


OPTIO IP Camera Range

It is possible to Pull RTSP streams via the following URLs

  • RTSP Streams
    • rtsp://<IPAddress>:554/cam/realmonitor?channel=1&subtype=0&unicast=true&proto=Onvif [Main Stream]
    • rtsp://<IPAddress>:554/cam/realmonitor?channel=1&subtype=1&unicast=true&proto=Onvif [Sub Stream]
  • Examples;
    • rtsp://username:password@192.168.30.220:554/cam/realmonitor?channel=1&subtype=0&unicast=true&proto=Onvif
    • rtsp://username:password@192.168.30.220:554/cam/realmonitor?channel=1&subtype=1&unicast=true&proto=Onvif



This completes the guide.
